| détails du produit |
| Diamètre de la lame: | 12 in |
| Capacité de coupe: | 1-31/32 x 8 in at 45 deg 1-7/32 x 8 in at 45 deg |
| Dimensions: | 24-5/8 in W x 30-23/32 in D x 27 in H |
| Contient: | 323522 12 in TCT Saw Blade 322995 Dust Bag 944458 Hex Bar Wrench 323657 Holder Assembly 322957 Vice Assembly 985051 Box Wrench |
| Maximum Bevel Angle: | 48 deg |
| Maximum Miter Angle: | 52 deg |
| Speed Rating: | 4000 rpm |
| Features |
| • | Exclusive laser marker system accurately indicates where the blade will cut on the material and can be easily adjusted to the right or left of the cut mark depending upon the users preference |
|
| • | Powerful 15 A motor with 1950 W of output power smoothly powers through hardwoods with ease |
|
| • | Tall, pivoting aluminum fence that stands at a height of 5-1/8 in allows crown molding to be cut vertically for convenience |
|
| • | Elastomer compound coats the horizontal handle, reducing vibration, while adding comfort and preventing slippage |
|
| • | Large base provides better support and balance to prevent material from warping |
|
| • | Externally accessible carbon brush for quick and easy maintenance |
|
| • | Miter scale ranges from 52 deg, both to the right and left, for a broader range of cuts |
|
| • | Miter angles can be quickly adjusted using Hitachi's thumb actuated positive stops |
|
| • | Bevel scale ranges from 48 deg to the right and left allowing the material to stay in place while the saw head flips to make opposing cuts |
|
| • | After major bevel angle is secured, micro-bevel adjustment knob can be used to dial-in to a precise angle without the weight of the saw head compromising the accuracy |
|
